GETAC, Handheld, PS535E

GETAC recommends Windows Vista® Business.


	Key features >

	MIL-STD-810F and IP54 compliance Microsoft Windows Mobile 5.0 Premium Transflective 3.5" TFT LCD Embedded high sensitivity GPS receiver Embedded 802.11 b/g and Bluetooth Long battery life provides all-day power

Specifications >

Model
Operating system	Microsoft Windows Mobile 5.0 (Premium edition)
Language	Traditional Chinese English
Ruggedness	Fully Rugged MIL-STD 810F and IP54 compliance Vibration & drop-shock resistant Tumbling 1000 Cycle
CPU	400MHz Samsung S3C2440A
Memory	64MB SDRAM
Storage	2GB NAND Flash
Display	Transflective 3.5" QVGA TFT LCD, 262,144 color Touch screen Sunlight readable display
Communication Interface	Bluetooth Class 2 V2.0+EDR WLAN 802.11 b/g
I/O Port	DC in x 1 USB 1.1 x 1 Microphone x 1 Speaker x 1 Line out x 1 MMCX GPS Antenna Connector
Memory Card Reader	SD card reader
Power	AC adapter (10W, 100-240V, 50/60Hz) Li-Ion smart battery (2400mAh, over 8 hours battery life at room-temperature operation with default settings)
Dimension & Weight	144.25 x 82.25 x 29.3 mm (5.68 x 3.24 x 1.15 in.), 300g (10.58 ounce)
Standard Software	Word Mobile, Excel Mobile, PowerPoint Mobile Internet Explorer Mobile Inbox, Calendar, Contacts, Instant Message, Tasks, Notes, Spell checker Microsoft Windows Media Player 10 Mobile Microsoft ActiveSync 4.5

Environmental Test Specifications >

Item	Test Criteria
Temperature	MIL-STD-810F, Method 501.4, Procedure I/II; MIL-STD-810F,Method 502.4 Procedure I/II • Operating: -20°C (4°F) to 60°C (140°F) • Non-operating: -30°C (-22°F) to 70°C (158°F)
Temperature Shock	MIL-STD-810F, Method 503.4 Procedure I
Humidity	MIL-STD-810F, Method 507.4
Shock	MIL-STD-810F, Method 516.5
Drop	MIL-STD-810F, Method 516.5, Procedure IV
Vibration	MIL-STD-810F, Method 514.5, Procedure I
ESD	IEC61000-4-2 / EN55024
Waterproof	IEC 529 IP-X4
Dustproof	IEC-529 IP-5X
Tumble	1,000 1.6 ft./.5 m tumbles (2,000 drops)
Regulation	CB, TUV, CE, UL/cUL, CNS14336(BSMI), FCC, NCC, CNS13438
Others	RoHS


	Accessories >

		Standard Accessories
	—	AC Charger with US/UK/EU plugs
	—	USB data cable
	—	Two stylus pens
	—	Microsoft Getting Started Disc(includes user manual)
	—	Hand strap
	—	Package of 10 screen protectors
	—	Quick Start Guide
	—	Warranty Card

		Optional Peripherals
	—	Vehicle Mount
	—	Vehicle Charger
	—	External GPS Antenna
	—	Cordless BT 1D Laser BCR
	—	Cordless HF RFID Reader
	—	Carry case with belt clip and neck strap

Sales kit >

Last Updated 04/18/2008
† Specifications subject to change without notice. Actual specifications are determined by individual dealers and may vary.
